Instructions

_{updated 01172025}

Required Materials:

Axle – 6mm Carbon tube or rod

Wing spar – 7mm x 500mm carbon tube or rod (or wood dowel)

Will require model print orientation manipulation during slicing i.e. the flattest side/surface of a model is usually the bottom layer.

FUSELAGE 3% Gyroidal infill single wall for the FUSELAGE – LWPLA

WING 2% Gyroidal infill single wall for the wing LWPLA

Tail surfaces 100% infill (or as close to it as possible)

Wing stays in PETG or PLA

Tires TPU, Main Wheels PETG/PLA

Rear Gear TPU! – dense infill i.e. 500 bottom layers. Use carbon fiber 1mm rod or steel wire for axle. Rear gear wheel is PETG or PLA.

Motor mounts PETG or PLA – 4S motor mount for larger motor suggested.

*** Recommend printing the beefy elevator and Fuselage 1 with the axle channel setup for rubber band shock absorber.
